Model
|
XJ1212
|
|
Working Area
|
1,200×1,200×100mm
|
|
Spindle Motor
|
1.5KW
|
|
Inverter-driven spindle motor cooled by water
|
|
Rotating Speed of Spindle
|
2,4000rpm
|
|
Working mode
|
Stepper
|
|
Drive mechanism
|
German imported ballscrew for x,y,z axis
|
|
Motion positioning accuracy
|
± 0.02/300mm
|
|
Repositioning accuracy
|
± 0.04mm
|
|
Max motion Speed
|
25,000mm/min
|
|
Max working speed
|
9,000mm/min
|
|
Engraving Tools
|
?3.175mm, ?6.00mm
|
|
Dictate Formate
|
G code
|
|
Operating voltage
|
AC220V/50/60Hz
|
|
Operating system
|
NC studio control system
|
|
Interface
|
USB
|
|
Flash Memory
|
128M
|
|
soft ware
|
Wentai software
|
Guarantee&Aftersales service:
a. guarantee for one year
b. 24 hour technical support by email or calling
c. User-friendly english manual for machine using and maintaining
